Send InquiryNotebook Cover Winding Machine
Price 62500 INR/ Unit
MOQ : 1 Unit
Notebook Cover Winding Machine Specification
- Phase
- Single
- Diameter
- Roller Diameter: 65 mm Millimeter (mm)
- Shape
- Rectangular Base
- Product Type
- Notebook Cover Winding Machine
- General Use
- Notebook Cover Binding and Winding
- Material
- Mild Steel & Stainless Steel
- Type
- Other
- Weight (kg)
- 300 Kilograms (kg)
- Computerized
- Yes
- Control System
- PLC Control
- Surface Treatment
- Powder Coated
- QC System
- Online Quality Inspection
- Tolerance
- 0.5 mm Millimeter (mm)
- Voltage
- 240 Volt (v)
- Dimension (L*W*H)
- 2150 x 850 x 1200 mm Millimeter (mm)
- Color
- Industrial Blue & Silver
- Lubrication System
- Automatic Lubrication Provided
- Roller Material
- Hard-Chrome Plated Steel
- Production Output
- Adjustable Speed Control
- Power Consumption
- 2.4 kW
- Operator Panel
- Ergonomic Design
- Packaging Type
- Wooden Box
- Working Temperature
- Up to 45°C
- Safety Feature
- Emergency Stop and Safety Guards
- Noise Level
- Below 65 dB
- Installation
- Onsite Installation Support
Notebook Cover Winding Machine Trade Information
- Minimum Order Quantity
- 1 Unit
- Payment Terms
- Cash in Advance (CID), Cheque, Cash Advance (CA)
- Supply Ability
- 10 Units Per Month
- Delivery Time
- 20 Days
- Main Domestic Market
- All India
About Notebook Cover Winding Machine
TechnicalSpeciation:
Â
Material will be Process: NotebookCover-HM Paper/Film
Roll Working Width: 16 inch-400mmStandard
Jumbo Roll Weight Capacity 30 Kg
Heavy Duty MS Plate Structure
1 No. Rubber Roll-Wrinkle Removing System
Core less Rewinding/ With Paper Core Rewinding
Motor 1 HP A.C. Motor
Control Panel 1 HP A.C.-Digital A.C. frequency Drive
(Penal Section we provide you Startand Stop Button, Length Counting meter, Speed adjustable, Sensor.)
Unwinder side Mechanical Shaft Chuck-Nut-Bearing use
Mechanical Break System for Tension Unwinder Jumbo Roll
Machine Speed: 100 meter/min.
Machine Available: Single/ Three Phase
High-Speed Production
Delivering remarkable results, this machine can process up to 1,500 notebook covers per hour. Its automated functionalities and high-torque motor make it ideal for businesses aiming to maximize output while maintaining precision and consistency.
Operator-Centric Design
Featuring an ergonomic operator panel and a touch screen, the Notebook Cover Winding Machine is tailored for convenient operation and user safety. Its intuitive interface allows for easy adjustments and real-time monitoring, promoting efficient workflow.
Advanced Safety & Durability
Equipped with emergency stop mechanisms, safety guards, and hard-chrome plated steel rollers, the machine prioritizes operator safety and longevity. The automatic lubrication system reduces wear and maintenance demands, while the powder-coated exterior ensures durability.
FAQs of Notebook Cover Winding Machine:
Q: How does the adjustable speed control work on the Notebook Cover Winding Machine?
A: The adjustable speed control allows operators to customize the machines winding speed according to the specific requirements of each production batch, ensuring optimal output and minimal errors.Q: What safety features are integrated into this winding machine?
A: This machine includes an emergency stop button and safety guards to protect operators during operation, ensuring a secure working environment at all times.Q: When should the automatic lubrication system be checked or maintained?
A: The automatic lubrication system is designed for continuous operation and minimal intervention. However, periodic inspection as per the manufacturers service guidelines is recommended to ensure consistent performance.Q: Where is onsite installation support available for this machine?
A: Onsite installation support is provided across India by the manufacturer, exporter, supplier, and wholesaler, ensuring the machine is set up correctly for efficient functioning.Q: What is the process for binding and winding notebook covers using this machine?
A: The process involves feeding notebook covers into the machine, which automatically winds and binds them using its high-torque motor, computerized PLC control, and hard-chrome plated rollers, followed by inspection using the integrated online QC system.Q: How can users benefit from the ergonomic design and user-friendly features of the operator panel?
A: The ergonomic operator panel and touch screen interface make the machine easy to use, enabling operators to adjust settings efficiently and monitor production for improved comfort and productivity.Q: What makes this machine advantageous for bulk notebook cover production?
A: With high-speed capability, low noise levels, fully automatic operations, and robust build quality, the Notebook Cover Winding Machine offers significant advantages for bulk production, including enhanced efficiency, reduced manual intervention, and superior quality control.
